Frequency Range (MHz)
|
2400-2500MHz/5150-5800MHz
|
|
Gain (dBi)
|
3-5
|
|
Horizontal Beamwidth (°)
|
360
|
|
VSWR
|
≤2
|
|
Input Impedance (Ω)
|
50
|
|
Maximum Power (W)
|
50
|
|
Lightening Protection
|
DC grounding
|
|
Mechanical Characteristics
|
|
|
Connector type
|
RP-SMA-J
|
|
Material
|
ABS
|
|
Mount way
|
Screw
|
|
Dimensions (mm)
|
158mm
|
|
Weight (g)
|
17
|
|
Environmental Characteristics
|
|
|
Noise Factor (dBi)
|
≤1.5
|
|
Operating Temperature (℃)
|
-30-+60°C
|
|
Relative Humidity
|
Up to 95%
|
|
ROHS Complaint
|
yes
|
