Center Frequency (MHz)
|
1100-1300MHz
|
|
Gain (dBi)
|
13dBI
|
|
Vertical Beamwidth (°)
|
28±4
|
|
Horizontal Beamwidth (°)
|
28±4
|
|
VSWR
|
≤2
|
|
Input Impedance (Ω)
|
50
|
|
Maximum Power (W)
|
100
|
|
Connector type
|
SMA-J or Customizable
|
|
Cable
|
RG58
|
|
Cable Length (Meter)
|
3m
|
|
Material
|
Aluminum Alloy
|
|
Mount Kits
|
U bolts
|
|
Dimensions (mm)
|
640mmx120mmx60mm
|
|
Weight (g)
|
373
|
|
Environmental Characteristics
|
|
|
Noise Factor (dBi)
|
≤1.5
|
|
Operating Temperature (℃)
|
-40-+80°C
|
|
Rated wind velocity(kph)
|
241
|
|
Relative Humidity
|
Up to 95%
|
|
ROHS Complaint
|
yes
|
