Sdantennas

2.4G Omnidirectional Portable External Wireless WIFI 2.4G Rubber Duck Antenna with RF Assembly Cable

Model: TSD-P2425Z06-011
2.4G Omnidirectional Portable External Wireless WIFI 2.4G Rubber Duck Antenna with RF Assembly Cable

Specifications

Model TSD-P2425Z06-011
Customization Standard Only
Material Fiberglass (FRP)

Key Features

  • ✓ High-strength fiberglass construction
  • ✓ Weather-resistant outdoor design
  • ✓ Excellent RF performance
  • ✓ Low maintenance requirements

Need a Quote?

Contact us for pricing, customization options, or technical specifications.

Send Inquiry Fast response within 24 hours

Product Description

Frequency Range (MHz)
2400-2500MHz
Gain (dBi)
2
Horizontal Beamwidth (°)
360
VSWR
≦1.92
Input Impedance (Ω)
50
Admitted Power
1W
Polarization
Line
Connector type
RP-SMA Male
Color
Black
Material
TPEE
operating Temperature (℃)
-20℃~+50℃
Storage Temp
-20℃~+50℃
